25-Series Mid-Size Single Auger Grain Carts

The Unverferth 25-Series single auger grain carts feature a side-folding auger design that tucks neatly along the tank's side.  This design allows the upper auger to be longer, equating to more side reach and greater height clearance.

The 14" diameter auger provides unloading speeds up to 300 bushels per minute and the 5/16” thick auger flighting provides long-term, trouble-free operation.

Electronic balancing of the upper and lower flighting ensures a smooth and efficient transfer of grain during each unload.

The spout-mounted LED unloading light makes for easy nighttime unloading.  The cushioned auger fold cylinder gently folds and unfolds the upper auger and when in the unload position, the pilot-operated check valve in the hydraulic system holds the upper and lower augers tightly together for a leak-free seal.

Models 6225 and 5225 feature tank capacities of 650 and 550 bushels to meet individual grower preferences.

The tank features an exclusive recessed auger sump design, located below the floor line of the tank, which funnels grain down into the auger for fast and complete unloading.  Steep 36° front and rear tank slopes and a graphite coated interior ensures complete cleanout and faster unloading speeds.

The hydraulically operated flow gate features a highly visible position indicator for easily controlling grain flow while unloading.

Model 6225 is standard with a single-tang hitch and model 5225 is standard with a clevis hitch for easy hookup and worry-free towing.

The heavy-duty side-wind jack is easy to operate for convenient tractor hookup and storage.

The exclusively designed, heavy-duty 45° gearbox features a 1 ¾” output shaft for long-term, trouble-free operation.  The 1 3/8” 21 spline shear-bolt PTO protects the driveline for longevity and durability.

The 25-Series is available with a high-flotation single wheel and tire and a rigid axle that can accommodate a wide range of tire sizes.

10-bolt hubs are manufactured from special alloy, high-strength steel with gusseted reinforcements for trouble-free operation.

Customize your 25-Series grain cart to fit your farming operation’s needs.  Choose a scale package, weatherguard roll-tarp or hydraulic drive to meet your operation’s needs!

The weatherguard rollover tarp option features a custom design for a sleek appearance and easy operation and the low-profile tarp bows are reinforced to eliminate sagging.  The heavy-duty, 18 oz. black canvas can withstand harsh weather conditions and the semi-trailer locking design provides optimum protection from high winds and moisture.

The optional hydraulic drive is tongue-mounted for easy installation and the grain cart can still be operated with a PTO if desired.  The 55 gallons per minute system provides up to 250 bushels per minute unloading speeds and requires 2 sets of hydraulic ports.

The 2-way directional downspout option provides in-and-out control for easily topping off trucks without re-positioning the tractor.

The 2-way directional downspout option provides in-and-out control for easily topping off trucks without re-positioning the tractor. This requires an additional SCV remote.
